1761 MP R Multi Purpose Beavertail

Flexible basis for highest precision

caliber .22 l.r.

Previous slide
Next slide

ANSCHÜTZ 1761 - Resting in oneself

Shooting is a complex, contradictory act, but ultimately, in the core of its being, it forces the shooter to re-examine himself. LOOK INWARD – BREATHE – STAY STILL – FEEL – CONCENTRATE … the actual triggering of the shot is almost of secondary importance. On this pages, you will experience the 1761 in its full range of detail. You will see the interplay of cleverly devised components produced with devotion and tested with meticulous attention to detail. The ANSCHÜTZ 1761.

FEATURES

Barreled action - 1761

What turns you on. Everything that makes an Anschütz.

ZK_hunting_1761_System_Perspective

Cocked barreled action, firing pin visible.

1 of 4

High-precision ANSCHÜTZ barrels offer the perfect prerequisite for high-precision point shots.

2 of 4

The integrated abutment provides additional and solid bedding in the socket.

3 of 4

The magazine release lever integrated in the trigger makes changing the magazine extremely quick and easy.

4 of 4
The foundation of our high precision rests on the barreled action design. Geometry inspired by our target rifles, with a high degree of stiffness, a flat supporting surface and an integrated recoil lug. The precision action is manufactured by highly demanding production processes and with gunsmiths expertise. In the action integrated well engineered ejector can be changed very easily. The luminous matte surface lends the model 1761 a timeless appearance, which will continue to look excellent even for many years to come.

bolt - 1761

Runs easy and quick

The bolt knob is made of high-strength synthetic and has a diameter of 25 mm. The bolt throw of the chamber is 60°.

1 of 4

The high-quality and resistant QPQ coating provides more sliding ability, wear resistance and corrosion protection.

2 of 4

The locking lug ensure maximum safety and phenomenal precision.

3 of 4

Idler pulley - for even easier and faster repeat.

4 of 4

The small bearing reduces the force needed to open and to close the bolt.Fast and easy repeats are possible. Symmetrically arranged three-lug locking mechanism for the highest safety and phenomenal precision. Simple disassembly for care and cleaning. The high-quality and resistant QPQ coating ensures additional sliding capacity, resistance to wear, and corrosion protection, and thus is perfect for use in hunting and for harsh weather conditions.

Triggers - 5061

Our tradition

More than 50 high-precision individual parts.

1 of 4

Ergonomic and silently operated fuse.

2 of 4

Multiple sliding and adjustable trigger blade - perfect to enable a safe and clean to release the trigger .

3 of 4

Ribbed trigger blade for best feel on the trigger finger.

4 of 4
Whether two stage trigger or single stage trigger - whichever position is preferred or is needed, whether prone position, sitting, kneeling or freehand standing position: With four different trigger options for the Model 1761, you will find the perfect interface between rifle and shooter. There is nothing better.

Magazine - 1761

Strong handling

The non-slip magazine base is made of high-strength synthetic, which is comfortable to hold even in cold temperatures.

1 of 2

The magazine is made of high-strength and robust steel - and is therefore insensitive to dust, dirt and water.

2 of 2

The single-row 5-shot magazine with robust stainless steel housing can be changed extremely quickly and easily. This is made possible by the release lever integrated in trigger guard in combination with the extended magazine base. The magazine base is made of high-strength and weather-resistant synthetic.

Action bedding - 1761

The base of precision

The additional abutment ensures precise and solid bedding.

1 of 2

Barreled action and stock lie absolutely flat on each other and thus provide the optimal basis for maximum precision.

2 of 2
The solid and flat bedding of the action in the stock guarantees the highest precision. The additional integrated abutment in combination with the flat contact surface of the system and the stock result in the optimal conditions for highest shooting precision.

Multi Purpose Beavertail Stock - 1761

With integrated clamping piece for butt plate carrier

Non-slip rubber butt plate, reduces recoil in the shoulder and provides the best grip in the position.

1 of 5

The buttstock is prepared for the aluminium butt plate carrier 4759. This allows the length of the buttstock to be individually adjusted.

2 of 5

The grip area has a non-slip stippled checkering that remains grippy even in wet weather.

3 of 5

The flat fore-end is equipped with an aluminium UIT rail which allows the attachment of accessories such as a hand stop.

4 of 5

The high-strength synthetic trigger guard protects the trigger from impacts and damage. Optionally also available as aluminum version.

5 of 5
Developed from the needs of the hunter from the "new world", this stock combines the advantages of a classic target shooting stock, combined with the wide, leading beavertail fore-end. The integrated UIT rail in fore-end impressively rounds off the overall package. The stock is prepared for mounting a butt plate carrier and can thus be flexibly adjusted in length.

Scope of delivery

The following items are always included in the delivery, regardless of how you configure the product!

  • 5-shot magazine
  • Styrofoam transport box

Item no\.\:\.\: 015539 (right hand version)

Item no\.\:\.\: 015773 (left hand version)

Configurator

Your personal 1761 - entirely according to your wishes

Content
    Add a header to begin generating the table of contents

    Version

    How to guide your rifle

    Right hand version

    Left hand version

    1761 - stock

    Aesthetic, timeless, individual

    1761 MP R Stock

    1761 - caliber

    Tailored to your needs

    .22 l.r.

    • number of grooves: 8
    • twist rate 420 mm

    1761 - barrel length

    Select your desired barrel length

    21.4 inches (544 mm), heavy with V-block and reinforced muzzle

    • Heavy barrel with V-block and reinforced muzzle.
    • Muzzle diameter 22 mm

    1761 - trigger

    Choose your perfect trigger

    two stage trigger 5061 Heavy

    • trigger weight, adjusted: 1.000 g
    • trigger weight, adjustable: 800 - 1,600 g
    • trigger blade longitudinally displaceable: 17 mm

    two stage trigger 5061 Light

    • trigger weight, adjusted: 300 g
    • trigger weight, adjustable: 250 - 500 g
    • trigger blade longitudinally displaceable: 17 mm

    single stage trigger 5061 D Heavy

    • trigger weight, adjusted: 1.000 g
    • trigger weight, adjustable: 800 - 1,600 g

    single stage trigger 5061 D Light

    • trigger weight, adjusted: 300 g
    • trigger weight, adjustable: 250 - 500 g

    single stage trigger 5061 D Tuning

    • trigger weight, factory set: 750 g
    • trigger weight, adjustable: 350 - 1.500 g
    • Versatile adjustable match tongues

    1761 - Magazine

    Simple handling, rapid ejection

    1761 Magazine, 5 shot

    1761 Magazine, 10-shot, .22 l.r.

    Single-row 10-shot magazine with stainless steel body. High-strength magazine base made of weather-resistant synthetic, for caliber 22.l.r.

    Only for caliber .22 l.r.

    1761 - Picatinny rail

    Assemble quickly and with repeat accuracy

    1761 prism rail 11 mm on reciever

    • Milled directly into the receiver at the factory

    1761 Picatinny rail, 0 MOA forward tilt

    1761 Picatinny rail, 30 MOA pre-tilt

    1761 - trigger guard

    Best protection for the trigger

    1761 trigger guard, synthetic

    1761 trigger guard, aluminum

    1761 - Chamber handle ball

    The individual touch

    Standard synthetic chamber handle ball, 25 mm

    Chamber handle ball walnut 20 mm

    Walnut chambered handle ball, 20 mm diameter.

    Chamber handle ball walnut 25 mm

    Walnut chambered handle ball, 25 mm diameter.

    Chamber handle ball steel burnished

    Steel chamber handle ball, black burnished, 25 mm diameter.

    Chamber handle ball Black Line

    Chamber grip ball "Black Line", deep black, DLC (Diamond Like Carbon) coated, 25 mm diameter.

    Chamber handle ball star in gold

    Chamber handle ball "Star in gold", with knurl-checkering, gold line and elegant star in gold, 25 mm diameter.

    Chamber handle ball checkering and silver line

    Chamber handle ball "checkering and line", with knurl-checkering and elegant, timeless silver line, 25 mm diameter.

    Chamber handle ball checkering and gold line

    Chamber handle ball "checkering and line", with knurl-checkering and elegant, timeless gold line, 25 mm diameter.

    Chamber handle ball silver line

    Chamber handle ball "Silver Line", with elegant, timeless silver line, 25 mm diameter.

    Chamber handle ball gold line

    Chamber handle ball "Goldline", with elegant, timeless gold line, 25 mm diameter.

    Chamber handle ball knurl with checkering

    Chamber handle ball "knurl-checkering", with grip knurl-checkering, timeless elegant in black, 25 mm diameter.

    APR bolt handle

    • Special APR bolt handle for fast repeat
    • Coated aluminum
    • Grippy, milled cross grooves

    1761 butt plate carrier

    Flexible adjustment of the length of pull

    Without butt plate boom

    Sheep cap boom LEIGHT, aluminum, silver color

    Sheep cap boom LEIGHT, aluminum, black

    Butt plate carrier Comfort

    The butt plate carrier allows adjustment of the buttstock length and height of the butt plate.

    1761 butt plate

    Lies stable and secure in the shoulder

    Without butt plate

    aluminum butt plate 4759

    aluminum butt plate 4759A

    rubber butt plate 4709A

    butt plate PREMIUM

    1761 hand stop

    Additional stability in the position

    Without hand stop

    hand stop 6226 with sling swivel

    For mounting on the aluminum UIT rail in the fore-end.
